The role of GNJBQ series mud agitator is to maintain the uniformity of the drilling fluid and suspend the solid particles, while continuously and reliably stirring the drilling fluid. GNJBQ series mud agitator is suitable for the agitation of petroleum drilling fluids. It has the advantages of compact structure, small footprint, and good mixing effect; Guanneng agitator can choose helical gear reducer or turbine worm reducer according to different customer requirements. It has the advantages of large transmission torque, stable operation and reliable work.
● Compact design. Quiet, smooth, vibration free.
● Durable, single reduction worm gear drive.
● Fewer moving parts, less maintenance.
● Compact design without coupling,JIE top brand gear box.
● C-Face Explosion proof electrical motor direct connection with gear box. ATEX,IEC Ex, and Marine Motors area available for option
● GN Special designed impeller completely made from casting to have better mixing performance
MUD MIXING TANK
CAPACITY: + 1000 GPM
JUMBO BAG SUITED
1 x Mixing Hopper: GNSLDSB
1 x Mixing Pump: GNSB8×6C-13J (50 HZ, 55 KW)
3 x GNJBQ110DD Ajitator (7.5 KW - 2 X 85 mm Impeller)
3 x GNNJQ - 80A -3X Mud Gun
INLET / OUT LET LINES TO / FROM TANK: 8 INCHES
CONNECTION TYPE: FIG 100 WING HAMMER UNION
Tank Land – Foot Print Dimension: Max Length: 12,012 mm X Max Wide 2,500 including Bottom Oil Filed Skid
