MANUAL TONG

MANUAL TONG FOR DRILL PIPE SIZE 3 1/2" - 17" VARCO HT65(WITHOUT GRIPPING JAWS) OR ANALOGUE TORQUE CAPACITY: 40,000 TO 65,000 LBS/FT, 1 (ONE) SET INCLUDING: LUG JAW ASSEMBLY 3 ½ "÷ 8 ¼"; LUG JAW ASSEMBLY 8"÷ 11 ¼"; LUG JAW ASSEMBLY 11 3/4"÷ 14 3/8"; LUG JAW ASSEMBLY 16"÷ 17"; HINGE JAW ASSEMBLY 8"÷ 17"; MOMENTOMER SET

US$ *0670.14SET

Model/PN: MANUAL TONG

Brand: RUTONG

Standard: API-7K

Lead Time: 80 days

Warranty: 12 Months

Place of Origin: China

Payment Method: T/T

Application: Oilfields equipments & Spares

Packaging: Export Standard Packing

HS code: 8431499900

Purchase Quantity

Add to Wishlist



Product Details

API Spec 7k C Type 2 3/8'' ~ 10 3/4'' HT 35 Manual Tong Tubular Drilling Tool

Description
Product Name:Manual TongMachine Type:Drilling Tool
Processing Type:Casting/forgingMaterial:Carton Steel
Use:Well DrillingApplication:Oil Field
Color:Red/Bule/YellowSize:2-3/8" ~ 10-3/4"
Latch Lug Jaw:5a~5e3Packing:Standard Exported Package
High Light:

HT 35 Manual Tong

,

Carton Steel Tubular Drilling Tool

,

10 3/4'' Manual Tong

API Spec 7k C Type 2 3/8 ~ 10 3/4" HT 35 Manual Tong Tubular Handling Tools



Manual Tong description of Tunular Handing Tools

Workover manual Tong is a kind of tool used for make-up/break-out drilling tools and pipes during workover and drilling water well operation or other drilling operations. The workover manual tong consists of tong handle, long jaw, short jaw, latch, locking handle, dies, etc.; the utility model workover manual tong reduces the sectional area and size of original tong, and changes the tooth-form on dies into double-arc rhombic-like convex shape, and a locking piece is installed at the tail end of the workover manual tong to prevent the wireline from sliding out and balance the tong head.


This workover manual tong is compact, light, and easy to operate with strong latching performance, and it is an ideal tool for well services. and this type tong can be adjusted by changing latch lug jaws.

API Spec 7k C Type 2 3/8'' ~ 10 3/4'' HT 35 Manual Tong Tubular Drilling Tool 0

API Spec 7k C Type 2 3/8'' ~ 10 3/4'' HT 35 Manual Tong Tubular Drilling Tool 1

Manual Tongs Datasheet of Tubular Handing Tools



No. Of

Latch Lug Jaw

No. Of

short Latch

No. of Hinge JawPipe sizeRated capacity
mminKN.m
1#1#/60.33~93.72 3/8~3 5/848
2#1#/73.03~1082 7/8~4 1/4
3#1#/88.9~133.3531/2~51/4
4#1#/133.35~177.851/2~7
5#2#1#177.8~219.087~8 5/8
6#2#1#244.5~273.059 5/8~10 3/4



HT Tong TypeSize Range Lever(Inches)Size Range Lever(mm)
HT142.3/8 - 760.3 - 177.8
HT352.3/8 - 10.3/460.3 - 273.1
HT553.1/2 - 13.3/888.9 - 339.7
HT653.1/2 - 1788.9 - 431.8
HT1004-17101.6 - 431.8
7.1/2 - 12190.5 - 304.8
HT2006-16203.2 - 406
HT5013.3/8 - 36339.7 - 914.4
